Water level

Water Level

For water level and depth measurement, no application is the same in surface and groundwater. OTT Hydromet offers a variety of sensors with different measurement principles, tailored to fit the specific requirements of different hydrologic measurement sites, including bubbler, pressure sensor, radar, and shaft encoder technology. Multiple telemetry options are also available for remote data acquisition

Our Products


OTT ecoLog 1000 Water Level Logger

The OTT ecoLog 1000 is a self-contained groundwater level logger for measuring water level and temperature, providing reliable and accurate data with integrated mobile communication.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell
Parameters measured: Water level/pressure, water temperature
Product Highlights: Integrated modem (4G / 2G), Bluetooth Low Energy (BLE), operation via APP, Lithium Powerpack with plug, exact battery level indicator, service life > 10 years
Measurement range: 0 … 4, 10, 20, 40, and 100m
Accuracy: ± 0.05 % FS
Internal data logger: Yes

Learn More

OTT SE 200

The OTT SE200 float-operated shaft encoder level sensor provides proven water level measurements in continuous, unattended monitoring in ground and surface water applications.

Application: Surface water, Groundwater
Measurement technology: Float-operated Shaft Encoder
Parameters measured: Water level
Product Highlights: Continuous water level measurement - for use with external data logger
Measurement range: ±30 m
Internal data logger: Yes
Interface: SDI-12 or 4 ...20 mA

Learn More

OTT Maximum Level Gauges

The OTT Maximum Level Gauge is a cost-effective measuring device that indicates the maximum water level by tidal waves or other level fluctuations over a color marking.

Application: Surface water
Measurement technology: Visual, color tape
Parameters measured: Water level
Product Highlights: Records high tide or surface water level
Measurement range: 1 m

Learn More

OTT Staff Level Gauges

Staff gauges from OTT as basic equipment for every level / discharge gauging station. And as all gauging stations are different, you can choose from several model variants.

Measurement technology: Visual
Parameters measured: Water level
Product Highlights: On-site water level reference
Measurement range: Customized
Accuracy: 2 cm

Learn More

OTT PLS - Pressure Level Sensor

The OTT PLS, SDI-12 or 4 ... 20 mA pressure probe, measures water level, depth to water, or pressure using an integrated controller and ceramic pressure-measuring cell.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell
Parameters measured: Water level, Pressure, Temperature
Product Highlights: Water level and temperature measurement - for use with external data logger
Measurement range: 0 … 4, 10, 20, 40, and 100m

Learn More

OTT Contact Gauges

OTT Contact Gauges are essential for manual water level measurements in groundwater. For measuring depth to water, temperature, and conductivity – depending on the variant.

Application: Groundwater
Measurement technology: Contact gauge
Parameters measured: Water level / Distance to water, Temperature, Conductivity
Product Highlights: Manual water level, temperature and/or conductivity measurement
Measurement range: Measuring tape lengths KL010: 15 ... 750 m; KL010 TM: 25 ... 500 m; KL010 TCM 30 ... 500 m

Learn More

OTT ecoLog 800 Water Level Logger

The OTT ecoLog 800 is a self-contained system for measurement of water level, temperature, and conductivity in groundwater and surface water applications.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell and 4-electrode graphite conductivity cell
Parameters measured: Water level/Pressure, Water temperature, Conductivity
Product Highlights: Measures, stores, and transmits water level and temperature data
Measurement range: 0 … 4, 10, 20, 40, and 100m
Accuracy: ± 0.05% FS
Internal data logger: Yes

Learn More

OTT ecoLog 500 Water Level Logger

The OTT ecoLOG 500 is a self-contained water level instrument offering flexible remote data options and unequaled performance for the price.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell
Parameters measured: Water level/Pressure, Water temperature
Product Highlights: Measures, stores, and transmits water level and temperature data
Accuracy: ± 0.05% FS
Internal data logger: Yes

Learn More

OTT RLS - Radar Level Sensor

The OTT RLS is a non-contact radar level sensor with pulse radar technology that is ideal for monitoring in remote or hard to reach locations

Application: Surface water
Measurement technology: Non-contact pulse radar
Parameters measured: Water level / distance to water
Product Highlights: Measures water level or depth to water from a bridge, pier or mounting arm
Measurement range: 0.4 … 35m
Accuracy: 0.8 … 2m: ± 10mm; 2 … 30m: ± 3mm; 30 … 35m: ± 10mm
Internal data logger: No
Interface: SDI-12, RS-485 (using SDI-12), or 4 ...20 mA

Learn More

OTT CBS - Compact Bubbler Sensor

The OTT CBS is a compact, accurate, and low power bubbler sensor for surface or groundwater level monitoring.

Application: Surface water, Groundwater
Measurement technology: Bubbler-in
Product Highlights: Drift-free water level measurement - no pressure sensor or electronics in the water
Measurement range: 0 to 15 m or 0 to 30 m
Accuracy: ± 3 mm (high accuracy version); ± 5 mm (standard and 30 meter versions)
Internal data logger: No
Interface: SDI-12, RS-485 (using SDI-12), or 4 ...20 mA

Learn More

OTT Orpheus Mini Water Level Logger

The OTT Orpheus Mini is an integrated pressure sensor and datalogger for level measurement in surface and groundwater applications.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell
Parameters measured: Water level/Pressure, Water temperature
Product Highlights: Measures and stores water level and temperature data
Measurement range: 0 … 4, 10, 20, 40, and 100m
Accuracy: ± 0.05% FS
Internal data logger: Yes

Learn More

OTT CTD Sensor

The OTT CTD is an integrated sensor and datalogger for measurement of water level, temperature, and conductivity in groundwater and surface water applications.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell and 4-electrode graphite conductivity cell
Parameters measured: Water level, Temperature, Conductivity
Product Highlights: Measures and stores water level, temperature, and conductivity data
Measurement range: Water level: 0 … 4, 10, 20, 40, and 100 m
Conductivity: 0.001…2.000 mS/cm, 0.10…100.00 mS/cm
Accuracy: ±0,05 % FS
Internal data logger: Yes

Learn More

OTT PLS-C

The OTT PLS-C measures water conductivity, level, and temperature in both surface and groundwater applications via a robust ceramic pressure cell and 4-electrode conductivity cell.

Application: Surface water, Groundwater
Measurement technology: Vented pressure cell and 4-electrode graphite conductivity cell
Parameters measured: Water level, Pressure, Conductivity, Temperature
Product Highlights: Water level, temperature, and conductivity measurement - for use with external data logger
Internal data logger: No
Interface: SDI-12 or RS-485 (using SDI-12)

Learn More
